VärmeKabelTeknik Switchpointheating



Components



Velox Switchpoint heating element

Heatingelementsaredeliveredincustomizedlengths

withfittedquick‐connectdevices.

Theelementsaretested,insulationmeasuredwithhigh

voltageappliedandmarkedwithtype.



Velox installation channels

Stainless‐steelchannelsaresuppliedinlengthsof1mor

0.5mandasstandardchannelsorslottedchannels,for

exampleforclearingthepointrodfasteningdevice.



ounting clips for Velox switchpoint heating

Normally,therequirednumberofclipsaresuppliedfor

installinganorderedswitchpointheatingsystem

comprisingelements,aconnectioncableandsensors.

Donotforgettostatethetypeofrailusedintheswitch.



Velox point rod heater

Thepointrodheaterismountedoverthepointrodpit.

Therodmustbekeptfreefromsnowandiceandheatis

suppliedtothecriticalpointsontheswitch.

Thepointrodheaterissuppliedintwocompletehalves,

whichareeasilymountedoverthepointrodpit.



Connectionismadetoaspeciallyorderedflexiblelead

connectormountedontheheatingelementforstock‐

rail.



Connection block for switchpoint heating

Waterproofrubberconnectingblocksmouldedinone

piece.

Theblocksaresuppliedcompletewithmountingplates

formountingonsleepersandtension‐relievingcovering

plates.

Theblockhasa4/8‐conductorconnectioncable

mouldedintoit,length10m.

Theblocksareavailablewith2or4outlets.




